HGM Ultra-fine Grinding Mill Working Principle
When the HGM Ultra-fine Grinding Mill is working, the main motor of the HGM Ultra-fine Grinding Mill drives the main shaft and the turntable to rotate through the reducer, and the roller pins on the edge of the turntable drive dozens of grinding rollers to roll in the grinding ring raceway.
Large materials are scattered to the periphery under the action of centrifugal force and fall into the grinding ring raceway to be impacted, rolled, and ground by the ring rollers. After being processed by the three-layer ring raceway, they become powder.
The high-pressure fan sucks the external air into the machine through suction and brings the crushed materials into the powder selector. The rotating impeller in the powder selector makes the coarse materials fall back to be re-grinded, and the fine powder that meets the requirements enters the cyclone powder collector with the airflow and is discharged from the discharge valve at the bottom as the finished product, while the airflow with a small amount of fine dust is purified by the pulse dust collector and discharged through the fan and muffler.
Maximino
From Saudi Arabia
"MAXTON mining equipment revolutionized our Saudi copper mine – handling 50°C desert heat without performance drops. The Arabic-speaking engineering team provided on-site training that cut our ramp-up time by 65%.After 18 months, their durable grinding mill show zero wear in our abrasive conditions. We consider MAXTON is a reliable partner for GCC mining projects. Would recommend them for friend."
Alexander
From Indonesia
"MAXTON has multiple projects in our area. I visited two of them, which gave me greater confidence in handing them over to us. Ultimately, our company purchased a MAXTON grinding mill production line, and the project passed inspection on the first try."
Jason
From USA
"After switching to MAXTON mining equipment, our productivity jumped 40% with half the maintenance costs. The German-engineered hydraulic system outperforms competitors in hard rock conditions.What truly impressed us was their 24/7 remote troubleshooting – a game-changer for our Denver iron ore site. Three years of zero unplanned downtime proves MAXTON’s ‘Built for Decades’ promise."
